TECHNICAL PARAMETERS
| Model | YDW-C100/YDW-C200/YDW-C300 |
|---|---|
| Laser source | JPT |
| Laser power(W) | 100w/200w/300w |
| wavelength(nm) | 1064 |
| Output Power(W) | >200 |
| Max.pulse energy(mJ) | 1.5 |
| Full power repetition rate range(kHz) | 120~2000 |
| Pulse repetition range(kHz) | 1~2000 |
| Pulse Duration(ns) | 10-350 |
| Longtime average power stability(%) | <5 |
| Cooling method | Air Cooling |
| Spectral width@3dB(nm) | <15 |
| Beam diameter（mm) | 6.5±0.5 |
| Power adjustment range(%) | 0-100 |
| Range of working temperature/℃ | 0-40 |
| Storage temperature range/℃ | _10~60 |
| Scan width(mm) | 130*130mm |
| Length of fiber(m) | 5 meters ( or customizable) |
| Laser grade | 4 |
| Control system | zbtk control system |
